Square D PowerPact HDL26080 H-Frame 2P 80A MCCB Lug 80%
150A Frame | 80A | 2P | 25kA@240V, 18kA@480V, 14kA@600V | Thermal-Magnetic (Fixed)
The PowerPact HDL26080 from Schneider Electric's Square D product line is a H-Frame 2-pole 80-amp circuit breaker designed for professional electrical installations and industrial systems. This MCCB delivers standard interrupting capacity of 25kA@240V, 18kA@480V, 14kA@600V at 600V AC / 250V DC for dependable overcurrent protection performance. The HDL26080 incorporates a TMD (Thermal-Magnetic) trip unit for reliable overcurrent protection including thermal overload and magnetic instantaneous response capabilities. This proven trip technology provides fixed protection characteristics precisely optimized for the H-Frame platform, ensuring consistent and dependable circuit protection across a wide range of operating conditions and fault scenarios. This unit mount breaker features lug (unit mount) connections with AL150HD Lug terminations, accepting 14-3/0 AWG Al/Cu conductors for versatile wiring applications. With overall dimensions of 5.90" H x 3.00" W x 3.63" D and weighing ~5 lbs, the HDL26080 delivers H-Frame frame protection in a space-efficient package suitable for dense electrical equipment layouts. UL 489 listed and CSA C22.2 No.5 certified, the HDL26080 meets IEC/EN 60947-2 international standards for global project specification and acceptance. Applications include feeder circuit protection, branch circuit protection, motor control center installations, panelboard and switchboard applications, and industrial power distribution systems requiring H-Frame frame-class protection capabilities. The HDL26080 exemplifies Schneider Electric's PowerPact platform engineering excellence, delivering consistent protection performance with robust construction designed for long service life in demanding environments.
Key Features
This PowerPact MCCB features Thermal-Magnetic (Fixed) trip protection rated 80A at 600V AC / 250V DC. Frame size: 150A. Interrupting capacity: 25kA@240V, 18kA@480V, 14kA@600V. Designed for reliable overcurrent protection in industrial and commercial power distribution systems.
Applications
Suitable for main distribution panels, motor control centers, switchboards, and feeder circuit protection in industrial facilities, data centers, and commercial buildings. Compliant with UL 489, CSA C22.2 No.5, IEC/EN 60947-2, NOM, CCC, CE.
