Square D PowerPact HJA36020 H-Frame 3P 20A MCCB I-Line
150A Frame | 20A | 3P | 100kA@240V, 65kA@480V, 25kA@600V | Thermal-Magnetic (Fixed)
Schneider Electric offers the Square D PowerPact HJA36020, a premium H-Frame 3-pole molded case circuit breaker delivering 20-ampere protection for critical electrical infrastructure and power distribution. With extra-high interrupting capacity of 100kA@240V, 65kA@480V, 25kA@600V, this MCCB operates at 600V AC / 250V DC to provide comprehensive and dependable circuit protection. This breaker incorporates a factory-calibrated TMD (Thermal-Magnetic) trip unit providing both thermal overload and instantaneous magnetic short-circuit protection. The H-Frame platform's proven trip mechanism ensures reliable operation with consistent and repeatable protection characteristics for dependable circuit protection throughout the breaker's entire service life. Configured for i-line plug-on installation, the HJA36020 utilizes i-line plug-on connections with I-Line Bus Connection terminations designed for reliable conductor termination. The unit accommodates 14-3/0 AWG Al/Cu conductors within compact overall dimensions of 9.70" H x 4.50" W x 5.17" D weighing ~8 lbs, optimizing installation density in electrical distribution equipment. Certified to UL 489, CSA, and IEC/EN 60947-2 international standards, the HJA36020 ensures compliance across diverse global markets and jurisdictions. This breaker serves commercial and industrial power distribution, feeder protection, motor circuit applications, and switchgear installations requiring dependable H-Frame frame interrupting performance. The PowerPact HJA36020 represents Schneider Electric's commitment to electrical safety, performance, and reliability in power distribution equipment for professional electrical installations worldwide.
Key Features
This PowerPact MCCB features Thermal-Magnetic (Fixed) trip protection rated 20A at 600V AC / 250V DC. Frame size: 150A. Interrupting capacity: 100kA@240V, 65kA@480V, 25kA@600V. Designed for reliable overcurrent protection in industrial and commercial power distribution systems.
Applications
Suitable for main distribution panels, motor control centers, switchboards, and feeder circuit protection in industrial facilities, data centers, and commercial buildings. Compliant with UL 489, CSA C22.2 No.5, IEC/EN 60947-2, NOM, CCC, CE.
